ARC60

● Ultra Compact Size: 2.92 x 1.85 x 0.91 inches
● Universal Input Range 90-264VAC, 47-440Hz
● I/O Isolation 4000VAC
● Operating Ambient Temperature Range -40°C to +85°C
● No Load Power Consumption < 0.1W
● High Efficiency up to 90%
● Screw Terminal for Option
● EMC Compliant without External Components
● Safety Approval to UL / IEC / EN 62368-1, IEC / EN 60950-1, IEC / EN 60335-1, IEC / EN 61558-2-16
● 3-Year Product Warranty

上一產(chǎn)品：AOCH10

下一產(chǎn)品：EPU16E(62368) series

產(chǎn)品描述

● All specifications valid at nominal input voltage,full load and +25°C after warm-up time unless otherwise stated.
● Measured with 0.1U 50V // 47U 50V Ceramic Cap. Cross to output.
● Please refer to the PDF file published on the web site as the final version.
● We reserve the right to make alterations in the product materials and specifications without prior notification and consent to improve reliability, function or design or otherwise.
